News
2021 - Radial Plug-flow Diffuser, type RPC-AD
Product Launch:
SMARTEMP is pleased to launch the Radial Plug-flow Diffuser, type RPC-AD, suitable for industrial displacement discharge from 4.5 to 8 m height. The discharge direction of the plug-flow air stream is adjustable from a radial pattern to a vertical airstream, providing both optimised cooling in which the low turbulence supply air spreads radially before gently falling downwards to floor level with minimal mixing, as well as effective heating to floor level by means of a strong downward airstream. Discharge direction adjustment is stepless, and may be manual, electric or by a self-powered thermal element in the supply air stream. DN400 and DN630 neck sizes are available, suitable for airflow rates from 450 to 1800 L/s. The diffusers are ideal for spot cooling/heating from large heights, as well as to purge contaminants from individual workspaces by displacing them from above with high quality supply air.
2020 - Belfast Campus, Ulster University, Northern Ireland, UK
Approximately 4000 patented floor swirl diffusers - SMARTEMP Inclined Floor Swirl Diffuser (ISF-AD) and SMARTEMP Auditorium Floor Swirl Diffuser (ASF-AD) - have been supplied for Ulster University's 75,000 m2 Belfast Campus. This landmark inner city redevelopment project is to provide a new vision for learning in the heart of Belfast for up to 15,000 students and staff.
2020 - 6 & 8 Parramatta Square, NSW, Australia
SMARTEMP have been selected for the 6 & 8 Parramatta Square project in Greater Western Sydney, set to be the largest commercial building in Australia.
The 55-storey, 233 m tall office tower has a total commercial floor area of 120,000 m2. It is expected to be complete by 2022
This 5 Green Star project features approximately 4500 SMARTEMP Fixed Helical Swirl Diffusers, type HSC-FD.
2020 - Helical Vari-Swirl®, type HSC-VS
Product Launch:
The SMARTEMP Helical Vari-Swirl®, type HSC-VS, is the industry's highest capacity electronic VAV swirl diffuser. Its patent pending variable geometry cyclone swirl damper provides low pressure operation, and increases discharge velocity when throttled to maintain throw even when turned down.
Unique features include:
- High capacity @ NC 30:
- DN355: 220 L/s @ 30 Pa static
- DN500: 330 L/s @ 30 Pa static
- 6 L/s minimum VAV airflow (pressure independent), equating to:
- DN355: turndown to 3% to 14% @ 30 Pa static, depending on airflow authority setting
- DN500: turndown to 2% to 10% @ 30 Pa static, depending on airflow authority setting
- Full airflow shut-off - cyclone and induction dampers fully seal (eliminates motorised duct shut-off dampers in multiple tenancy applications)
- Low operating pressure (10 Pa min)
- Low supply air temperature (≥7°C)
- Six reconfigurable airflow authority settings - active damper opening adjustable from 100% to 20% in successive steps of approx 30% (ideal for base-building to tenancy conversions, and for future-proofing designs)
- Powerful induction system for accurate on-board room air sensing of temperature, humidity and CO2 or VOC
- Connection box with:
- R1 thermal insulation
- Acoustic attenuation
- Interchangeable side-entry spigots
- Low profile options (200 mm minimum)
Further on-board sensors include: supply air temperature (cooling/heating change-over); supply air pressure (airflow measurements); PIR (to determine occupancy) and Bluetooth (for communication with remote sensors, commissioning, and set-point adjustment from a user’s personal device).
The stepper motor, zeroing micro-switch, PC board, Bluetooth antenna and all sensors are accessible from below for maintenance and upgrades – no ceiling void access required.
To achieve a common aesthetic within the building, the face of the Helical Vari-Swirl (HSC-VS) matches SMARTEMP's Fixed Helical Swirl (HSC-FD) and Adjustable Helical Swirl (HSC-AD) diffusers.
2020 - Kirdorfhaus, Hamburg, Germany
Bespoke SMARTEMP Perforated Multistream Wall Diffusers, type PMW-AD, have been supplied for the refurbishment of the heritage listed Kirdorfhaus at Ballindamm 17 in Hamburg.
The seven-storey building is being extensively gutted and revitalised, with the historical condition being partially restored. In 1901/02 the architects Lundt & Kallmorgen designed the office building for the trading and shipping company A.C. de Freitas & Co. In 1905 and 1921, two further building sections were completed, which means that the building now features three components from different years of construction.
2020 - Te Pae Christchurch Convention Centre, Christchurch, New Zealand
Visitors to conferences and exhibitions in the $475 million Te Pae Convention Centre, currently under construction in Christchurch, will benefit from Smartemp air diffusion.
The following SMARTEMP air diffusion products are being supplied:
- SMARTEMP Linear Multistream Ceiling Diffusers, type LMC-AD
- SMARTEMP Circular Nozzle Cassettes, type CNW-AD-cassettes
- SMARTEMP Adjustable Helical Swirl Diffusers, type HSC-AD
Te Pae is purpose designed to be flexible, and will have capacity to host up to 2,000 delegates for a variety of national and international events. It will feature world-class purpose-built facilities including a 1,400 seat auditorium, 3,600 square metres of exhibition space and 24 meeting rooms.
2020 - National Assembly Building, Luanda, Angola
Bespoke, curved SMARTEMP Linear Multistream Ceiling Diffusers, type LMC-AD have been selected for Angola's parliament, the National Assembly Building of Angola.
These SMARTEMP high induction linear diffusers, with manually adjustable micro-jets, will ensure that parliamentarians enjoy the highest levels of draught-free comfort during parliamentary debates.
2020 - University of Stirling Sports Centre, Stirling, UK
Air diffusion products by Smartemp have been selected for the University of Stirling Sports Centre development, including:
The redevelopment will see Scotland’s University for Sporting Excellence create an iconic new sports complex that will be integrated with existing world-class facilities.
The new building will include purpose-built studios, an innovative fitness suite, three-court sports hall, indoor cycling studio, strength and conditioning area, as well as a new state-of-the-art high-performance suite
2020 - Meadowbank Sports Centre, Edinburgh, Scotland, UK
Air diffusion by Smartemp has been selected for the Meadowbank Sports Centre redevelopment in Edinburgh.
The redevelopment will feature a host of Smartemp products, including:
- SMARTEMP Rectangular Plugfow Diffusers, type RPW-AD
- SMARTEMP Inclined Floor Swirl Diffusers, type ISF-AD
- SMARTEMP Circular Nozzles, type CNW-AD
- SMARTEMP Adjustable Helical Swirl Diffusers, type HSC-AD
- SMARTEMP Jet Swirl Diffusers, type JSC-AD
The new £47 million sports centre is to include:
• An outdoor athletics track with a 500 seat stand
• Two multi-sport games halls
• Three fitness studios
• A gym
• A gymnastics hall
• Two squash courts
• A combat studio for martial arts
• A boxing gym with ring
• A 60m six-lane indoor athletics track and jumps space
• An outdoor throwing area
• Two Fifa-standard 3G pitches - one in the centre of the athletics track
• Cafe and meeting rooms
2020 - HSC-AD: DN400 & DN630
Due to popular demand, the SMARTEMP Adjustable Helical Swirl range of diffusers, type HSC-AD, has been expanded to include neck sizes DN400 and DN630.
The full range of HSC-AD neck sizes available is:
- DN250-R1
- DN250-R0
- DN355-R1
- DN355-R0
- DN400-R0 - NEW
- DN500-R1
- DN500-R0
- DN630-R0 - NEW
- DN710-R1
- DN710-R0
- DN1000-R1
- DN1000-R0 - the world's highest capacity commercially available swirl diffuser
For further information, visit SMARTEMP Adjustable Helical Swirl Diffusers, type HSC-AD
2019 - Her Majesty's Theatre, Adelaide, Australia
SMARTEMP air diffusion has been selected to provide audience comfort to Her Majesty's Theatre in Adelaide.
Originally opened in 1913 as a Tivoli theatre, with each of Australia's capitals boasting one of the iconic theatres, Her Majesty's in Adelaide is the only one now remaining. The renewal of this proud old theatre will take approximately 15 months, with the venue undergoing a major makeover. When it opens in 2020 the $ 66 million refurbishment will include restoration of the building's heritage facade, and will boast a new auditorium with 1474 seats over three levels, along with new foyers, backstage facilities and a new front entrance.
The following SMARTEMP air diffusion products are being supplied:
- SMARTEMP Auditorium Displacement Step Diffusers, type ADS-FD
- SMARTEMP Auditorium Floor Swirl Diffusers, type ASF-AD
- SMARTEMP Inclined Floor Swirl Diffusers, type ISF-AD
- SMARTEMP Perforated Multistream Wall Diffusers, type PMW-AD
- SMARTEMP Linear Multistream Ceiling Diffusers, type LMC-AD
- SMARTEMP Circular Nozzles, type CNW-AD
- SMARTEMP Adjustable Helical Swirl Diffusers, type HSC-AD, with electric actuators
Diffuser Supply: Air Diffusion Agencies
Builder: Hansen Yuncken
Mechanical Consultant: Aurecon
Lead Architect: Cox Architecture
2019 - Arthur Phillip High School & Parramatta High School, NSW, Australia
SMARTEMP Perforated Multistream Wall Diffusers, type PMW-AD, along with SMARTEMP Linear Multistream Ceiling Diffuser, type LMC-AD, are being supplied to the new high-rise Arthur Phillip High School accommodating up to 2,000 pupils and the new multi-storey 1,000 pupil facility for Parramatta Public School.
The first of its kind for the NSW Government, the project will be a showcase for the delivery of multi-storey education facilities in response to metropolitan Sydney's increasing residential density.
2019 - Quartermile, Edinburgh, Scotland, UK
SMARTEMP have been selected for the Q3 Quartermile project in Edinburgh.
The £35m Foster + Partners-designed six-storey building provides 7,000 m2 of Grade A office accommodation at Quartermile, an investment managed by Moorfield Group.
Called Quartermile 3, it brings the combined gross development value of projects currently underway at Quartermile to in excess of £185m and will create employment opportunities for around 700 people.
The project features SMARTEMP Fixed Helical Swirl Diffuser, type HSC-FD.
Diffuser Supply: Advanced Airflow Solutions
SMARTEMP at ISH 2019, Frankfurt, Germany
Australian engineered Smartemp diffusers are raising the bar at the largest building services fair in the world: Frankfurt's ISH 2019 expo, open from Sun 10th March - Fri 15th March 2019.
SMARTEMP's Adjustable Helical Swirl Diffusers, type HSC-AD, Perforated Multistream Wall Diffusers, type PMW-AD and Inclined Floor Swirl Diffusers, type ISF-AD may be seen at the LTG stand in Hall 8.0, stand D50.
LTG is a Stuttgart based German leader of specialist air diffusion, and has partnered with Smartemp to complete its range.
2018 - Sydney Opera House Function Centre, Australia
SMARTAIR DIFFUSION is proud to have advised on the air diffusion design, and to be awarded the contract to supply its SMARTEMP Linear Multistream Ceiling Diffusers, type LMC-AD, for the Function Centre of the Sydney Opera House Renewal project. The bespoke solution includes gently curved versions of these diffusers abutting the radiused perimeter beam above the floor-to-ceiling northern windows that offer stupendous views of Sydney Harbour.
The SMARTEMP high induction linear diffusers with manually adjustable micro-jets will ensure that events, from weddings through to intimate gatherings and small-scale performances in this, one of the world's most spectacular locations, will be cocooned in comfort.
Diffuser Supply: Idealair Group
Mechanical Contractor: Engie
Mechanical Consultant: AECOM
2018 - McLaren Automotive, Yorkshire, UK
SMARTEMP Cylindrical Plug-Flow Diffusers, type CP-AD, are being supplied to the new £ 50 million McLaren manufacturing facility in Sheffield. The low turbulence plug-flow air streams from these diffusers will provide enhanced indoor air quality to the factory floor of the McLaren Composites Technology Centre, where the ultra lightweight carbon fibre tubs for the monocage chassis of the entire McLaren luxury family of sportscars and supercars will be made. Diffuser discharge direction is adjusted by thermally powered actuators, to ensure draught-free cooling and effective heating year round.
Diffuser Supply: Advanced Airflow Solutions
2018 - Adelaide Botanic High School, Australia
SMARTEMP Perforated Multistream Wall Diffusers, type PMW-AD are being supplied to the new $ 100 million Adelaide Botanic High School. These patented high induction wall diffusers will compliment quality learning with enhanced levels of draught-free comfort.
Other SMARTEMP air diffusion products being supplied include high capacity fixed vane ceiling swirl diffusers (SMARTEMP Fixed Helical Swirl Diffuser, type HSC-FD) and electrically adjustable variable discharge pattern ceiling swirl diffusers (SMARTEMP Adjustable Helical Swirl Diffuser, type HSC-AD).
Diffuser Supply: Air Diffusion Agencies
Mechanical Contractor: O'Connors Mechanical Construction (SA)
Mechanical Consultant: AECOM
2018 - Barrack Pl, 151 Clarence St, Sydney, Australia
SMARTAIR DIFFUSION has been awarded the contract to supply SMARTEMP air diffusion products for the next generation PCA A-grade workplace coming to Sydney. The 18 storey, 22,000 m² building is designed to achieve a 5-star Green Star and a 5-star NABERS Energy rating, and has been awarded Australia’s first ever WELL Core & Shell Precertification at the Gold level by the International WELL Building Institute™ (IWBI™).
Tenants at Barrack Place will enjoy enhanced health and wellness benefits. More than 1000 patented floor swirl diffusers (SMARTEMP Inclined Floor Swirl Diffuser, type ISF-AD) will provide occupants with the highest levels of thermal climate customisation, by allowing individual user adjustability of both diffuser airflow rate and air motion.
Ceiling air diffusion from almost 700 fixed vane swirl diffusers (SMARTEMP Fixed Helical Swirl Diffusers, type HSC-FD), along with high induction adjustable linear diffusers (SMARTEMP Linear Multistream Ceiling Diffuser, type LMC-AD), both designed specifically for low temperature VAV applications, will provide fan energy savings and a draught-free, pleasant climate, whilst wall mounted thermally adjustable nozzles (SMARTEMP Circular Nozzle, type CNW-AD) will ensure that guests entering the building are welcomed in comfort.
Diffuser Supply: Idealair Group
Mechanical Contractor: AG Coombs
Mechanical Consultant: ARUP
2018 - BBC, Cardiff, Wales, UK
SMARTEMP has developed highly technical solutions to serve acoustically sensitive areas and studios at the BBC Wales facility in Cardiff. This development has involved extensive testing in the Smartemp laboratory. The project features bespoke radial swirl diffusers (new product, SMARTEMP Multiswirl Ceiling Diffuser, type MSC-FD), inductive sidewall diffusers (SMARTEMP Perforated Wall Diffuser, type PMW-AD), and ceiling outlets (SMARTEMP Fixed Helical Swirl Diffuser, type HSC-FD).
The technical fit-out began in April 2018 and is expected to take around 18 months. BBC staff will begin the move to the new building in the autumn of 2019 and it will be fully operational in 2020.
Diffuser Supply: Advanced Airflow Solutions
2018 - 839 Collins St, Melbourne, Australia
SMARTAIR DIFFUSION has been awarded the contract to supply in excess of 5000 floor swirl diffusers (SMARTEMP Inclined Floor Swirl Diffuser, type ISF-AD) to the 839 Collins St project in Melbourne. These patented floor swirl diffusers provide users with the highest level of thermal climate customisation, by allowing individual user adjustability of both diffuser airflow rate and air motion.
The site will become a 20-level office tower featuring 38,000 m² of A-grade commercial space.
The property is being developed by Lendlease and is located adjacent to ANZ's global headquarters. ANZ will lease 26,500 m² of the 6-star Green Star environmental rated building.
The building is the first in Melbourne designed to achieve workspace ratios of 1 person per 8 m².
Diffuser Supply: Idealair Group
Mechanical Contractor: AG Coombs
Mechanical Consultant: Aurecon
2018 - V&A Museum, Dundee, Scotland, UK
SMARTEMP Adjustable Helical Swirl Diffusers, type HSC-AD, have been supplied to the prestigious V&A Museum in Dundee. These high capcity swirl diffusers for large volume spaces include variable discharge direction adjustment via thermal wax elements to provide draught-free cooling and effective heating from elevated heights.
In a development worth over £ 80 million, Scotland's first design museum is the centrepiece of Dundee's £ 1 billion regeneration project, which is forecast to attract hundreds of thousands of tourists and millions of pounds of investment to the city.
Diffuser Supply: Advanced Airflow Solutions
